Introducing 3D CAD data (STEP) to the website.
2023/05/30
Introducing 3D CAD data (STEP) to the website.
Reflecting needs from users to the website
With the appearance, spread, and performance improvement of personal computers, design methods have changed from handwriting to 2D, “3D” that does not require advanced drawing comprehension, and 3D data started to increase in the needs for manufacturers. At MAXPULL MACHINERY & ENGINEERING CO., LTD., we will meet these changing expectations and have built a new system to provide “3D data”.
■ Even those who cannot open a STEP file can feel free to experience the 3D data.
“iCAD 3D browser” is posted on website’s top page and product list.
You can check the sample product from various angles with a simple mouse operation without dedicated software. In addition, you can also check the cut plane of the internal structure by clicking [Internal display] button as demonstration.
■ “STEP file (3D)” can now be downloaded from the website.
“STEP file (3D)” has been added to the drawing data of each product at “Download CAD data” within the website.
You can easily comprehend the shape by operating this data and design image is intuitively conveyed to the client and the persuasiveness increases. We will continue to post traditional 2D data (DXF). Please use the data according to the software you are using.
